Popis produktu:
General
Model # / Part #
See P/N Selector Tab
See P/N Selector Tab
Interface
SATA 6Gb/s
SAS 12Gb/s
Capacity (GB)
6TB / 4TB
6TB / 4TB
Sector Size (Variable, Bytes/sector)
4Kn: 4096
4Kn: 4096, 4104, 4160, 4224
512n*/512e: 512
512n*/512e: 512, 520, 528
Max Areal Density (Gbits/sq. in.)
512e/4Kn: 782, 696 (4TB)
512e/4Kn: 782, 696 (4TB)
512n*: 753
512n*: 753
Form Factor
3.5-inch
3.5-inch
Performance
Data Buffer (MB)
256
256
Rotational Speed (RPM)
7200
7200
Latency Average (ms)
4.16
4.16
Interface Transfer Rate (MB/sec, max)
600
1200
Sustained Transfer Rate
512e/4Kn: Up to 255MB/s; Up to 243MiB/s
512e/4Kn: Up to 255MB/s; Up to 243MiB/s
512n*: 233MB/s; 222MiB/s
512n*: 233MB/s; 222MiB/s
Seek Time (read, ms, typical)
8.0 (read) / 8.6 (write)
8.0 (read) / 8.6 (write)
Reliability
Error Rate (non-recoverable, bits read)
1 in 10 15
1 in 10 15
MTBF (M hours)
2M hours
2M hours
Annual Failure Rate (AFR)
0.44%
0.44%
Load/Unload Cycles
600,000
600,000
Availability (hrs/day x days/wk)
24x7
24x7
Limited Warranty (yrs)
5
5
Acoustics
Idle (Bels)
2.9
2.9
Operational (Bels, typical)
3.6
3.6
Power
Requirement
+5V, +12V
+5V, +12V
Operating (W, typical)
7.0
12.1
Idle (W)
5.9
7.0
Physical Size
Z-Height (mm)
26.1 (max)
26.1 (max)
Dimensions (width x depth, mm)
101.6 (+/-0.25) x 147
101.6 (+/-0.25) x 147
Weight (g, max)
715
715
Environmental (operating)
Ambient Temperature
5°C to 60°C
5°C to 60°C
Shock (half-sine wave)
70G (2 ms)
70G (2 ms)
Vibration
0.67G RMS (XYZ, 5 to 500Hz)
0.67G RMS (XYZ, 5 to 500Hz)
Environmental (non-operating)
Ambient Temperature
-40°C to 70°C
-40°C to 70°C
Shock (half-sine wave)
300G (2 ms)
300G (2 ms)
Vibration
1.04G RMS (XYZ, 2 to 200Hz)
1.04G RMS (XYZ, 2 to 200Hz)
