HPE Networking Instant On Switch 8p Gigabit 1430 (R8R45A)

HPE Networking Instant On Switch 8p Gigabit 1430
General Information
Product Name: HPE Networking Instant On Switch 1430 8-Port Gigabit
Product Number: R8R45A
Differentiator:
Unmanaged, plug-and-play switch for small businesses and home offices. No configuration required. Provides reliable Gigabit connectivity.
Ports
Total Ports: 8 RJ-45 autosensing ports
Port Speeds Supported:
10/100/1000 Mbps (IEEE 802.3, 802.3u, 802.3ab)
Duplex Modes:
10/100 Mbps: Half or Full Duplex
1000 Mbps: Full Duplex only
Performance
Throughput: 11.90 Mpps (Million packets per second)
Switching Capacity: 16 Gbps
Packet Buffer Size: 2.0 Mb
Memory: 128 Kb EEPROM
Power
Power Supply: External Power Adapter
Input Voltage: 100–240V AC
Power Consumption:
Maximum: 12W
Idle: 1.7W
Management Features
Type: Unmanaged (no management interface or configuration needed)
Environmental Specifications
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Physical Characteristics
Dimensions: 13.8 x 15.7 x 3.7 cm
Weight: 0.59 kg
HPE Networking Instant On Switch 8p Gigabit 1430 (R8R45A) (R8R45A)
I/O ports and slots
8 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
Dimensions
138(d) x 157(w) x 37(h) mm
Weight
1.30 lb (0.59 kg)
Processor and Memory
128Kb EEPROM; Packet buffer size: 2.0 Mb
100 Mb latency
< 2.7 Î1Sec
1000 Mb latency
< 1.80 Î1Sec
Throughput (Mpps)
11.90 Mpps
Capacity
16 Gbps
MAC address table size
8192 entries
Reliability MTBF (years)
416.2
Operating temperature
32°F to 104°F (0°C to 40°C)
Operating relative humidity
15% to 95% @ 104°F (40°C) non-condensing
Nonoperating/ storage temperature
-40°F to 158°F (-40°C to 70°C) up to 15000 ft
Nonoperating/ storage relative humidity
15% to 90% @ 149°F (65°C) non-condensing
Altitude
up to 10,000 ft (3 km)
Acoustics
Fanless
Frequency
50Hz/60Hz
AC voltage
100-240VAC
Current
0.3A (12VDC - 1A)
Maximum power rating
12W
Idle power
1.7W
PoE power
-
Power Supply
External Power Adapter
Safety
EN/IEC 60950- 1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
EN/IEC 62368-1, 2nd. & 3rd. Ed.
UL 62368-1, 3rd. Ed.
CAN/CSA C22.2 No. 62368-1, 3rd. Ed.
EN/IEC 60825- 1:2014 Class 1
Emissions
EN 55032:2015/ CISPR 32, Class B
FCC CFR 47 Part 15: 2018, Class B
ICES-003, Class B
VCCI-32, Class B
CNS 13438, Class B
KS C 9832, Class B
AS/NZS CISPR 32, Class B
Immunity
BS/EN 55035, CISPR 35, KS C 9835
Generic
EN 55035, CISPR 35
EN
EN/IEC 61000-4-2
ESD
EN/IEC 61000-4-3
Radiated
EN/IEC 61000-4-4
EFT/Burst
EN/IEC 61000-4-5
Surge
EN/IEC 61000-4-6
Conducted
EN/IEC 61000-4-8
Power frequency magnetic field
EN/IEC 61000-4-11
Voltage dips and interruptions
EN/IEC 61000-3-2
Harmonics
EN /IEC 61000-3-3
Device Management
Unmanaged
Mounting
Mounting positions and supported racking
Supports table-top mounting
Supports wall-mounting with ports facing either up or down using base surface mounting holes
Supports under-table mounting using base surface mounting holes
HPE Networking Instant On Switch 1430 Series
Key Features
Unmanaged Layer 2 Gigabit Ethernet switch series ready to deploy in 5-, 8-, 16-, 24-, and 26-port models
Up to 124W of PoE to power APs, IP Phones, and other IoT devices
No configuration or management needed
Plug-and-play with fully automated functions and zero ongoing maintenance
Quality of Service (QoS) and flow control for improved network efficiency
Fan-less with Energy Efficient Ethernet for low power consumption
Class B certified for home office networks (5 and 8 port models)
Standard Features
Simplicity at its Best
Plug-and-play switches that work right out of the box
Zero configuration required
Reliable Connectivity
Connect faster with Gigabit Ethernet speed
PoE to power devices like APs and IP phones
We"ve Got You Covered
Industry-leading limited lifetime warranty and support
24 x 7 chat support for entire warranty period
The Networking Instant On Differentiators
Better Together

HPE Networking Instant On products work together to provide a seamless Wi-Fi experience. Wired and wireless voice traffic is prioritized with high QoS priority end-to-end for optimal voice performance.

Industry-Leading Support and Warranty

Expert-level support and industry-leading limited lifetime warranty are also included, along with chat support for the life of the product.

Additional Highlights
Plug-and-Play: Gigabit Ethernet speeds
Duplex Support: Half/full-duplex auto-negotiating capability on access ports
Fiber Uplinks: 26-port model includes two 1G SFP fiber ports for long-distance connectivity
Simplified Cabling: Auto MDI/MDI-X for cable type detection
PoE Certification: IEEE 802.3at (Class 4) and 802.3af compliant for APs, IP phones, etc.
EAPoL Forwarding: Supports 802.1x authentication forwarding
STP BPDU Forwarding: Ensures proper Spanning Tree operation to avoid loops
Traffic Optimization
QoS: Prioritizes voice/video traffic via DSCP and IEEE 802.1p
Flow Control: Helps prevent packet loss at congested nodes
Jumbo Frame Support: Up to 9216 bytes for large file transfers
Warranty, Service, and Support

HPE Networking Instant On Limited Lifetime Support provides:
24x7 phone support for the first 90 days
24x7 chat support for the entire warranty period
Community support for the lifetime of the product PE Networking Instant On Switch 1430 Overview
HPE Networking Instant On Switch 1430 Overview

Technology brings new revenue opportunities, more effective communication, and improved productivity to businesses of all sizes. Yet it also poses daily challenges of configuration and maintenance, especially for small businesses who lack IT support. Small offices and home offices need reliable network connectivity that"s fast, configuration-free, and affordable for even the most budget-strapped businesses.
The HPE Networking Instant On Switch 1430 is a plug-and-play unmanaged switch series for small businesses looking for simple, reliable, and low-cost network connectivity. These easy-to-use switches deliver Layer 2 Gigabit Ethernet switching capabilities—at an affordable price point—to help connect and share common resources like printers and access points, without any complicated network configuration.
With plug-and-play operation, fully automated functions, zero ongoing maintenance, and Power over Ethernet (PoE) models, these switches deliver simple, reliable connectivity for the smallest SMBs and home offices.

Model Availability

The HPE Networking Instant On Switch 1430 series includes seven models in both PoE and non-PoE configurations:
1 × 5-port model
2 × 8-port models
2 × 16-port models
1 × 24-port model
1 × 26-port model with 2 SFP uplinks
PoE Capabilities

The PoE models support up to 30W per port (Class 4 PoE), suitable for powering:
Access Points
Surveillance Cameras
VoIP Phones
Power budgets:
8-port PoE model: 64W
16-port PoE model: 124W
Designed for Small Business

All switches are fan-less, making them ideal for acoustically sensitive environments such as home offices and meeting rooms. These switches are unmanaged and require no configuration—they are not managed by the HPE Networking Instant On cloud portal.
