Popis produktu:
1x 16GB UDIMM DDR5-4400 Non-ECC
Memory Slots4 DDR5 DIMM slots, 2 channels capable
Max MemoryUp to 128GB (4x 32GB DDR5 UDIMM)
PCIe NVMe ControllerIntegrated NVMe® Controller
PCIe NVMe Drive1x 512GB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal
SATA ControllerOnboard Intel® RSTe SATA RAID
SATA/SAS DriveNone
Storage SupportUp to five drives (4x HDD + 1x M.2 SSD) or six drives (3x HDD + 3x M.2 SSD)
• 3.5" HDD up to 6TB each
• 2.5" HDD up to 1TB each
• M.2 SSD up to 4TB or 2TB each (see Storage Type)
OpticalNone
Audio ChipHigh Definition (HD) Audio, Realtek® ALC897Q-CG codec
Power Supply500W Platinum Fixed
Supports four PCIe® slots with two PCIe 4.0 x16 and two PCIe 3.0 x1.
• Slot 1: PCIe 4.0 x16, full height, full length, 75W, double-width
• Slot 2: PCIe 3.0 x1, full height, half length, 25W
• Slot 3: PCIe 4.0 x16 (x4 lanes), full height, half length, 25W
• Slot 4: PCIe 3.0 x1, full height, half length, 25W
BaysUp to four disk bays:
• Bay 1 supports one 3.5" / 2.5" drive, standard
• Bay 2 supports one 3.5" / 2.5" drive, optional
• Bay 3 supports one 3.5" / 2.5" drive, optional
• Bay 4 supports one 3.5" / 2.5" drive, optional
• Front Access HDD Bay supports one 3.5" / 2.5" drive, optional, occupies Bay 3 location
Dimensions (WxDxH)180 x 370 x 415 mm (7.09 x 14.57 x 16.34 inches)
Weight13.61 kg (30.0. lbs, maximum configuration)
1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), data transfer only
2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
2x USB-A (USB 10Gbps / USB 3.2 Gen 2)
1x headphone / microphone combo jack (3.5mm)
1x microphone (3.5mm)
Rear Ports
4x USB-A (USB 5Gbps / USB 3.2 Gen 1), one supports Smart Power On
1x HDMI® 2.1 TMDS
2x DisplayPort™ 1.4
1x Ethernet (RJ-45)
1x line-out (3.5mm)
Optional Rear Ports (configured)None
MANAGEABILITY
System ManagementIntel® vPro® Enterprise with Intel AMT 16
ISV CertificationsPlease visit ISV certifications for Lenovo® Workstations
