SUPERMICRO 40x40x28 mm, 22.5K RPM, SC813MF Middle Cooling Fan

Nidec (W40S12BS1D5-57T03A) FAN-0154L4 is a standard fan for CSE-113MFTS, CSE-801LTS, and CSE-813MFTS series chassis. This fan has been fully tested and validated by Supermicro to ensure the best quality and cooling performance.
Manufacturer
Nidec
Fan Size
40mm
Rated Fan Speed
22500 RPM
Acoustic Noise Level
61 dBA
Maximum Airflow Rate
28.6 CFM
Rate Current (A)
1.05A
Connector
4 Pin
Dimensions
40L x 40H x 28W (mm)
Validated Chassis
CSE-113MFAC2-341CB, CSE-113MFAC2-605CB, CSE-113MFAC2-R606CB, CSE-113MFAC2-R608CB, CSE-113MFAC2-R804CB, CSE-513BTQC-350B, CSE-513BTQC-350WB, CSE-813MF2TQC-505CB, CSE-813MF2TQC-R608CB, CSE-813MF2TQC-R804CB, CSE-813MFTQ-R606CB, CSE-813MFTQC-350CB2, CSE-813MFTQC-505CB, CSE-813MFTQC-505CB2, CSE-813MFTQC-R407CB, CSE-813MFTQC-R608CB2
Search Terms
40mm fans, 40mm, A8-04028ANI-004T001, B8-04028ANI-011T001, W40S12BS1D5-57T07
Warranty
1 year warranty
Product Environmental Compliance
RoHS and REACH compliant, details available upon request
