Dynatron A26 - Active 2U Cooler for AMD® WRX8, SP3, TRX4, TR4, 280W

Recommend for AMD® Ryzen Threadripper Processor, SocketsWRX8,sTRX4 , TR4, and AMD® Epyc Processor Socket SP3, Side-Blower 60x60x25mm PWM fan, Support CPU power up to 280 Watts heat dissipation.
Additional Information
CPU Support
AMD
CPU Socket
sWRX8/sTRX4/TR4/SP3
Solution
2U Server and Up
Dimensions
119.0 x 79.0 x 65.0 mm
Weight
450g
Material
Aluminum Heatsink with Heatpipe Embedded
Fan Dimension
60 x 60 x 25 mm
Speed
At Duty Cycle 20%: 1600 ± 200 RPM
At Duty Cycle 50%: 4000 ± 10% RPM
At Duty Cycle 100%: 8000 ± 10% RPM
Power
At Duty Cycle 20%: 1.2W
At Duty Cycle 50%: 2.28W
At Duty Cycle 100%: 7.2 W
Bearing
Ball Type, Double
Rated Voltage
12V
Air Flow
At Duty Cycle 20%: 8.85 CFM
At Duty Cycle 50%: 21.88 CFM
At Duty Cycle 100%: 43.75 CFM
Noise Level
At Duty Cycle 20%: 18 dBA
At Duty Cycle 50%: 37.9 dBA
At Duty Cycle 100%: 53 dBA
Air Pressure
At Duty Cycle 20%: 0.76mm-H2O
At Duty Cycle 50%: 4.76mm-H2O
At Duty Cycle 100%: 19.04mm-H2O
Lead Wire Pin Out
Pin1- (-)
Pin2- (+)
Pin3- (Techometer/Signal output)
Pin4- (PWM)
*All product specifications and product images are subject to change without notice.
