TP-Link EAP772 OMADA WiFi7 AP v2.0 (P, N:0153501242) (BE9300,2,4GHz, 5GHz, 6GHz, 1x2,5GbELAN, 1xPoE+)

TP-Link EAP772
Přístupový bod BE9300 Tri-Band WiFi 7 pro montáž na strop
BE9300 Tri-Band Wi-Fi 7 (5760 Mb/s na 6 GHz + 2880 Mb/s na 5 GHz + 574 Mb/s na 2,4 GHz).
Čisté pásmo 6 GHz přináší čistší a širší zdroje.
1× 2,5G port uvolňuje plný potenciál Wi-Fi 7.
Šířka pásma 320 MHz umožňuje mnohem více současných přenosů.
Provoz s více linkami a více jednotkami zajišťuje vysoký výkon vaší sítě.
Pokročilé funkce: Centralizovaná správa, mesh a AI roaming.
Stránky produktu: https://www.tp-link.com/cz/business-networking/omada-wifi-ceiling-mount/eap772/
Technické specifikace
HARDWARE FEATURES
Interface 1× 2.5G Ethernet Port
Button Reset
Power Supply 802.3at PoE or 12V/2.5A DC
Power Consumption • 24.05 W (For PoE);
• 20.92 W (For DC)
Dimensions ( W x D x H ) 8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm)
Antenna Type • 2.4 GHz: 2× 4.0 dBi
• 5 GHz: 2× 5.0 dBi
• 6 GHz: 2× 5.0 dBi
Bluetooth 1 × 4.0 dBi, Bluetooth 5.2
*Firmware update may be required.
Mounting Ceiling / Wall Mounting (Kits Included)
WIRELESS FEATURES
Wireless Client Capacity 380+
Wireless Standards IEEE 802.11 a/b/g/n/ac/ax/be
Frequency 6 GHz, 5 GHz, and 2.4 GHz
Signal Rate 574 Mbps (2.4 GHz) + 2880 Mbps (5 GHz) + 5760 Mbps (6 GHz)
Wireless Functions • MLO‡
• 4K-QAM‡

• Seamless Roaming(802.11k/v/r)
• MU-MIMO‡
• EHT320‡
• Mesh?
• BSS Coloring‡
• OFDMA‡
• Load Balance
• Band Steering
• Beamforming
• Airtime Fairness
• Multiple SSIDS:24(8 on each band)
• Wireless Schedule
• Reboot Schedule
• QoS(WMM)
• Rate Limit
• Static IP/Dynamic IP
• RADIUS Accounting
• MAC Authentication
Wireless Security • Captive Portal Authentication?
• Access Control
• Maximum number of MAC Filter: 4,000
• Wireless Isolation Between Clients
• VLAN
• Rogue AP Detection
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power < 20 dBm (2.4 GHz, EIRP)

< 23 dBm (5 GHz, band 1&band 2, EIRP)

< 28 dBm (5 GHz, band 3, EIRP)

< 23dBm (6 GHz, EIRP)
MANAGEMENT
Omada App Yes
Centralized Management • Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
Cloud Access Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller.
Email Alerts Yes
LED ON/OFF Control Yes
Management MAC Access Control Yes
SNMP v1, v2c, v3
System Logging Local/Remote Syslog Yes
Web-based Management Yes
OTHERS
Certification CE, FCC, RoHS, IC
Package Contents • EAP772
• Installation Guide
• Ceiling/Wall Mounting Kits
Note: Power Adapter is NOT included.
Environment • Operating Temperature: 0 °C–40 °C (32 °F–104 °F);
• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
• Operating Humidity: 10%–90% non-condensing;
• Storage Humidity: 5%–90% non-condensing;
