Popis produktu:
SATA
SAS
General
Interface
SATA 6 Gb/s
SAS 12 Gb/s
Capacity
18TB / 16TB
18TB / 16TB
Format: Sector size (bytes)
4Kn: 4096
4Kn: 4096, 4112
512e: 512
4160, 4224
512e: 512, 520, 528
Performance
Data buffer (MB)
512
512
Rotational speed (RPM)
7200
7200
Sustained transfer rate
(MiB/s, typical)
257/250
257/250
(MB/s, typical)
269/262
269/262
Reliability
Error rate (non-recoverable bits read)
1 in 10
1 in 10
MTBF (M hours, projected)
2,5
2,5
Annualized Failure Rate (AFR, projected)
0.35%
0.35%
Load/Unload cycles (at 40°C)
600
600
Availability (hrs/day x days/wk)
24x7
24x7
Limited Warranty (yrs)
5
5
Acoustics
Idle/Operating (Bels, typical)
2.0/3.6
2.0/3.6
Power
Requirement
+5 VDC, +12VDC
+5 VDC, +12VDC
Operating (W)
6,5
8,8
Idle (W)
5,6
5,8
Power consumption efficiency at Idle
0.31/0.35
0.32/0.36
(Watts/TB)
Physical Size
z-height (mm)
26.1
26.1
Dimensions (width x depth, mm)
101.6 (+/-0.25) x 147
101.6 (+/-0.25) x 147
Weight (g, max)
690
690
Environmental (Operating)
Ambient temperature
5°C to 60°C
5°C to 60°C
Shock (half-sine wave, 2ms, G)
70
70
Vibration-Operating (G RMS, 5 to 500 Hz)
0.67 (XYZ)
Environmental (Non-Operating)
Ambient temperature
-40°C to 70°C
-40°C to 70°C
Shock (half-sine wave, G)
250 (2ms)/ 150 (11ms)
250 (2ms)/ 150 (11ms)
Random Vibration (G RMS, 2 to 200 Hz)
1.04 (XYZ)
1.04 (XYZ)
