Popis produktu:
Informace k záruce:
Na produkt je poskytována omezená doživotní záruka, to znamená, že záruční lhůta vyprší až pět let poté, co společnost D-Link (nebo její nástupce) ukončí prodej daného produktu v Evropě.
Pro nárok na omezenou doživotní záruku je třeba produkt zaregistrovat (viz níže) u D-Link Europe do třiceti (30) dnů od data zakoupení. Registraci lze provést přes samoobslužný portál.
Popis
The DGS-3630 Series Layer 3 Stackable Managed Switches are designed for Small Medium Businesses (SMBs), Small Medium Enterprises (SMEs), larger Enterprises, and ISPs. They deliver high performance, flexibility, fault tolerance, and advanced software features for maximum return on investment. With Gigabit Ethernet RJ45 and SFP ports, 10 GbE SFP+ ports, advanced security features, and advanced Quality of Service (QoS), the DGS-3630 Series can act as core, distribution or access layer switches. High port densities, switch stacking, and easy management make the DGS-3630 Series suitable for a variety of applications.
Technická specifikace
Technical Specifications
Interfaces
• 10/100/1000BASE-T Ports
20
• Combo 10/100/1000BASE-T or SFP Ports
4
• 10 Gigabit SFP+ Ports
4
• Console Port
RJ45 and Mini USB console ports for out-of-band CLI management
• Management Port
10/100/1000BASE-T RJ45 Ethernet for out-of-band IP management
• Alarm Port
RJ45
• USB Port
USB 2.0 Type A
• Optional Redundant Power Supply
DPS-500A
Performance
• Switch Capacity
• 128 Gbps
• Packet Forwarding Rate
95.24 Mpps
• Packet Buffer
4 MBytes
• MAC Address Table
68K entries
• IPv4 Routing Table
16K entries
• IPv6 Routing Table
7K entries
• IPv4 Forwarding Table
32K entries
• IPv6 Forwarding Table
16K entries
• Jumbo Frame Size
12 KBytes
Physical and Environmental
• MTBF
300,190 hours
• Acoustics
52.7 dB(A)
• Heat Dissipation
145 BTU/hr
• Power Input
• 100 to 240 VAC, 50/60 Hz
• Max Power Consumption
42.4 W
• Standby Power Consumption
28.1 W
• Dimensions
441 x 260 x 44 mm
• Weight
3.74 kg
• Ventilation
• 2 Smart Fans
• Operating Temperature
-5°C to 50°C
• Storage Temperature
-40°C to 70°C
• Operating Humidity
10% to 95% RH
• Storage Humidity
5% to 95% RH
• Safety Certifications
cUL, CB, CE, CCC, BSMI
• EMI/EMC
CE, FCC Class A, C-Tick, VCCI, BSMI, CCC
